High Resolution Encoders & Low Cost Encoders
-
R35i Rotary Encoders
Application: Servo
Signal Period per Resolution (CPR): 100, 200, 250, 256, 400, 500, 512, 625, 800, 1000, 1024, 1250, 2000, 2048, 2500, 4000, 4096, 5000, 8000, 8192, 10000
Commutation: With or without
Shaft Diameter: Metric: 4 mm, 5 mm, 6 mm, 8 mm
Inch: 1/8, 1/8+, 3/16, 3/16+, 1/4, 1/4+, 5/16, 5/16+, 3/8, 3/8+
Interface: Square-wave signals with differential line driver as per RS 422, Square-wave signals with push-pull single-ended driver output
Voltage Supply: +5 V ±5 %
PCB Connector: Radial or Axial
Solid Shaft Encoders
Application: Industry
Resolution (CPR): 100-3600
Working Voltage: 5-24V
Output Circuit: E, C, L, F
Small size, light weight and easy installation
More Information
Hollow Shaft Encoders
Application: Industry
Resolution (CPR): 100-3600
Working Voltage: 5-24V
Output Circuit: E, C, L, F
Small size, light weight and easy installation
More Information
Servomotor Dedicated Encoders
Application: Industry
Resolution (CPR): 100-3600
Working Voltage: 5-24V
Output Circuit: E, C, L, F
Small size, light weight and easy installation
More Information
Low Cost Encoders
Application: Industry
Resolution (CPR): 50-2048
Working Voltage: 5V
Output Circuit: E, C, L
More Information
